Schneider AEG DR-1060-300

1. Overview

Schneider AEG DR-1060-300 is part of the low-voltage switchgear system, mainly applied to the main power distribution of industrial plants, commercial buildings and power distribution networks. It integrates circuit breakers, disconnectors, fuses, relay protection, measuring instruments and other components, providing a highly reliable power distribution solution.

2. Specifications

Rated Voltage: 10kV (High-voltage side) / 0.6kV (Low-voltage side)Rated Current: 1000A (Single-busbar system)Pole Number: 3P (Three-phase)Switching Mode: Rear-mounted busbar (MLS structure)Short-time Withstand Current: 50kA (Standard design)Protection Class: IP4X (Electric shock protection)Structure Type: Modular, scalable to add or reduce sub-units as required

3. Product Features

Modular Design: Adopts MLS (rear-mounted busbar) structure. All core electrical components including circuit breakers and disconnectors are installed behind the busbar, facilitating maintenance and operation while effectively reducing hazards caused by arc faults.
High Reliability: With a long-standing reputation in the power distribution equipment industry, Schneider AEG products are renowned for stability and durability, ideal for harsh industrial environments.
Flexible Expansion: Supports customized configurations of busbar quantity and protection devices (e.g. overvoltage protection, leakage protection) based on actual demands.
Excellent Safety: Equipped with standardized switch operating mechanisms and interlocking devices to ensure safety during maintenance.

4. Structure & Components

Main Switch Unit: Includes high-voltage side circuit breakers, low-voltage side disconnectors and fuses.
Measurement & Protection Devices: Comprises current transformers (CT), voltage transformers (VT) and various relay protection devices.
Operating Mechanism: Offers manual or electric operation options, usually with remote control function.
Cabinet Structure: Steel cabinet with integrated busbars and accessories, enabling convenient on-site installation and maintenance.

5. Application Fields

Industrial Power Distribution: Main power distribution rooms of large-scale manufacturing enterprises, supplying power to all production workshops.
Building Power Distribution: Main power distribution equipment for high-rise buildings.
Power System: Used as main switchgear in substations and distribution stations of power distribution networks.

6. Installation & Maintenance

Installation Requirements

Install in a dry, well-ventilated environment with sufficient operating space around the equipment. Avoid exposure to dust and chemical corrosion.

Maintenance Recommendations

Regularly inspect terminals and fasteners to ensure firm connection.
Test insulation resistance periodically to maintain electrical safety.
Check lubrication status of mechanical operating mechanisms.
Verify normal operation of interlocking devices.Thanks to the rear-mounted busbar design, maintenance personnel do not need direct contact with high-voltage side core electrical components, greatly improving operational safety.

——————————————————————————————-
